Main Characteristic:
1.Operating radius is small, can work in a small area,suitable for groove backfill;
2.With CHAICHAI engine or famous water-cooled diesel engine,superior performance,easy to operate;
3.With international famous brand PH hydraulic drive unit,infinitely variable speed;
4.Hydraulic steering,reversing conveniently; Vibratory Road Roller
4.Internationally renowned Bearings,to ensure the work performance of machine;
LTC301
Main Technical parameters
| Model | LTC301 |
| Operating mass | 1035kg |
| Vibration amplitude | 0.5mm |
| Centrifugal force | 25Kn |
| Vibration frequency | 54Hz |
| Travel speed | 0-3Km/h |
| Grade ability | 30% |
| Overall dimension (LxWxH) | 2005x896x2062mm |
| Front Vibration drum diameter | 530mm |
| Front Drum width | 800mm |
| Diesel engine power | 8.2hp |
| Diesel engine model | CF192FA |
| Fuel tank capacity | 5.5L |
| Ship | 6units/40HQ |
